15.6" capacitive touchscreen, 1920*1800 pixel, 16 million true colors;
Dual Ethernet ports and dual serial ports design, flexible communication;
Quad-core CPU + 1GB RAM + 8GB flash storage, ultimate performance;
Metal casing + PCB coating + power isolation, safe and reliable;
15.6" TFT
344.16mm(W)x163.2mm(H)
1920*1080px
16.2M
89/89/89/89(L/R/U/D)
1000:1
LED
300cd/m²
30000 hours
Reinforced glass capactive touch panel
Quad-core ARM 1.8GHz
8GB eMMC +1GB RAM
Built-in RTC + 512KB recipe
1 USB Host
1 USB Host
LAN0:10/100/1000 Mbps
Ethernet port/USB Slave/U disk
COM0:RS232/RS485/RS422;COM2:RS232
DC18V～DC28V, built-in isolated
15W@DC24V
<3ms
Over 50MΩ@500V DC
500V AC 1 minute
YES
Metal
397*297*46mm
Cantilever installation
118*70mm
4KG
0~50℃
10~90%RH (non-condensing)
-20~60℃
10~90%RH (non-condensing)
10~500Hz, 30m/s², X,Y,Z direction/hour
Natural air cooling
Conforming to IP65 requirements
CE Compliant(EN61000-6-4:2007+A1:2011，EN61000-6-2:2005)
Kinco DToolsPro
